published by StefanoConverso on Lun, 18/10/2010 - 17:14
We participated to the 2010 Italian edition of BIM Conference in Milan.
We took part to the DesignSlam session, where a kiosk and a big roof
were requested to cover courtyards of an existing given building.
We responded by developing a solution based on a parametric family
joining a column with a series of suspended transparent panels.
Rather than developing a continuous surface, the 30 minutes project is
based on the proliferation of the base component, able to be instanciated
and variated to build the requested roof over the different parts.
The family is based on an adaptive component, categorized as structural column,
and it has another nested adaptive component for the panels. It has 4 shape handles
that attach to existing points, referenced to a base variable angle on the Left/Right plane.
