Few procedures to set Project Vasari and basic skills to work with.

After you download and save Project Vasari, launch it and make sure your settings are right. Click manage and then project units and specify units of measure, the precision and the appropriate symbol for the units you're using.

Procedimento realizzazione palazzina via A. Dulceri 24 ,con  Vasari.

1)      Menage → project units → lenght → metres

2)      Analyze → location →indirizzo → importt image

3. Model → create mass → line →tangent end arc

4)      Create forme → solid → modifica misura h

5)      Finish mass

6)      Sun path on → shadows on → imposto ora e data

Fine

Per prima cosa, una volta aperto il modello, ho impostato secondo la mia esigenza le unità di misura del disegno:

Manage->Project Units->Lenght=metres

                                                Area= squared metres

Analisys of the sun shading on a building in Rome, via Vivanti.

1. set the location.

2. extruded volume through the "create mass" command.

3. indicated number of planes and set their height.

4.added the sun path and shadows.

5. verified preciseness of shadows via photo.
